1. Mini thickness rau chrome tawv yog 0.6 hli, precision ± 0.1 hli, rau limed daim tawv nqaij yog 1 hli, precision ± 0.2 hli.
2. PLC tswj qhov system, tag nrho cov khoom hluav taws xob nrog dej pov thawj, nco txhua ib zaug nres hluav taws xob.
3. Muaj peev xwm ua tau qhov kev hloov pauv tsis tau rau hauv cov ntawv qhia zaub mov, hloov kho hauv qhov chaw.
4. Nws muaj ib tug high reset precision ntawm cov menyuam pub mis thiab cooper menyuam.
5. Qhov chaw txheeb ze ntawm cov nylon cov menyuam thiab cov menyuam pub mis tuaj yeem hloov kho manually.
6. Nrog rau qhov system, nce, ntog thiab khoov ntawm cov menyuam noj thiab cov menyuam tooj liab, qhov tsis tuaj yeem hloov kho.
7. Lub sharpness txheeb ze txoj hauj lwm nrog pub rau cov menyuam, cooper cov menyuam los ntawm kev tswj digital.
8. Lub siab phaj pem hauv ntej ntug txoj hauj lwm los ntawm digital tswj.
9. Lub phaj siab tuaj yeem qhib thiab kaw, yooj yim los hloov thiab ntxuav.
10. Txoj hauj lwm ntawm rab riam yog qhov tseeb orientation qhov rhiab heev yog 0.02mm, thiab thim rov qab sai.
11. Tsau tsis siv neeg braking ntaus ntawv thaum lub nplhaib riam tawm ntawm txoj hauj lwm, xyuas kom muaj kev nyab xeeb.
12. Yooj yim los hloov cov riam riam, tsis tas yuav tshem tawm cov ncej spline thiab cardan sib koom thiab lwm yam.
13. Nruab nrog kab rov tav conveying ntaus ntawv ntawm daim tawv nqaij qis, tuaj yeem tawm ntawm daim tawv nqaij ntawm sab laug lossis sab xis, hloov tau yooj yim.
14. Yooj yim rau ntxiv txiav txav tawm ntawm daim tawv nqaij thaum faib cov tawv nqaij tawv.
15. Tsau tsis siv neeg lubrication ntaus ntawv.
| Technical Parameter |
| Qauv | Ua haujlwm dav (mm) | Pub ceev (m / min) | Tag nrho lub zog (kW) | Qhov Loj (mm) L × W × H | Qhov hnyav (kg) |
| GJ2A10-300 | 3000 | 0-42 ib | 26.08 Nws | 6450 × 2020 × 1950 hli | 8 500 |
